LOADCELL CAS BCL- 10kg

Max. capacity	kgf	1,2, 3, 6, 10, 15, 20, 30, 60, 100, 150, 200
Rated output Zoro balance	mV/ V mV/ V	2.0 ± 0.2 0 ± 0.1
Combined error Repeatability Creep for 30min. Temperature effect on Zero Value Output value	% % % %/ 10℃ %/ 10℃	0.03 0.01 0.03 0.028 0.014
Excitation Recommended Maximum Resistance Input Output Insulation	V V Ω Ω MΩ	10 15 400 ± 20 350 ± 3.5 ＞2,000
Compensated temperature range Operating temperature range	℃ ℃	-10 to +40 -20 to +70
